| Order No. | Insert | Dimensions(mm) | Shim | Shim Screw | Locking Screw (R) | Locking Screw (L) | Wrench | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Right/Left |  |
DC | DCSFMS | LF | DCON | DCON(inch) | I No. |  |
 |
 |
 |
 |
|
| SF5063R/L | SF..1504 | 63 | 60 | 50 | 22 | 1" | 4 | SMS-53 | CSA4009F | CS6-0823L | CS6-0823R | FT-7 | TW040 |
| SF5080R/L | 80 | 65 | 50 | 27 | 1" | 5 | |||||||
| SF5100R/L | 100 | 77 | 50 | 32 | 1-1/4" | 6 | |||||||
| SF5125R/L | 125 | 90 | 63 | 40 | 1-1/2" | 7 | |||||||
| SF5160R/L | 160 | 129 | 65 | 40 | 2" | 7 | |||||||
