| Order No. | Insert | Dimensions(mm) | Parts | Wrench | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Right/Left |  |
H | B | LF | LH | WF | TH |  |
 |
 |
 |
 |
 |
 |
| AAWLNR-2020K08WP | WNMG0804 | 20 | 20 | 125 | 40 | 25 | 1/8" | SMT-432 | CSF4010 | CP-AX01 | SP0710 | CSH0516 | CS9NQ CS9-3003 |
TL-20 LW025 LW040 |
| AAWLNR-2525M08 | 25 | 25 | 150 | 40 | 32 | 1/8" | ||||||||
| AAWLNR/L-2525M08WP | 25 | 25 | 150 | 40 | 32 | 1/8" | ||||||||
WP：Multiple coolant direction
