▼Recommended Inserts: ISCAR / ACC / WALTER
| Order No. | Insert | Dimensions(mm) | Screw | Wrench | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Right / Left |   |
DC | LF | DCX | DCON | DCON(inch) | I No. |  |
 |
|||
| F45SN13-05004 | SNMX1205 SNEX1205 SNMU1205 ONMU1205 |
50 | 40 | 63 | 22 | - | 4 | CSR5014 | DBIT-T15 | |||
| F45SN13-06306 | 63 | 40 | 76 | 22 | 1" | 6 | ||||||
| F45SN13-08007 | 80 | 50 | 93 | 27 | 1" | 7 | ||||||
| F45SN13-10008 | 100 | 50 | 113 | 32 | 1-1/4" | 8 | ||||||
| F45SN13-12510 | 125 | 63 | 138 | 40 | 1-1/2" | 10 | ||||||
| F45SN13-16012 | 160 | 63 | 173 | 40 | 2" | 12 | ||||||
| F45SN13-20014 | 200 | 63 | 213 | 60 | 1-7/8" | 14 | ||||||
| F45SN13-25016 | 250 | 63 | 263 | 60 | 1-7/8" | 16 | ||||||
