| Order No. | Insert | Dimensions(mm) | Parts | Wrench | |||
|---|---|---|---|---|---|---|---|
| Right/Left |  |
柄高 | 柄寬 | 長度 | 工作寬度 |  |
 |
| H | B | LF | WF | ||||
| SCMCN-1212H09 | CCMT09T3 | 12 | 12 | 100 | 6 | CS35090 | FT-15 |
| SCMCN-1616H09 | CCMT09T3 | 16 | 16 | 100 | 8 | CS35090 | FT-15 |
| SCMCN-2020K09 | CCMT09T3 | 20 | 20 | 125 | 10 | CS35090 | FT-15 |
| SCMCN-2525M09 | CCMT09T3 | 25 | 25 | 150 | 12.5 | CS35090 | FT-15 |
| SCMCN-2020K12 | CCMT1204 | 20 | 20 | 125 | 10 | CS40115 | FT-15 |
| SCMCN-2525M12 | CCMT1204 | 25 | 25 | 150 | 12.5 | CS40115 | FT-15 |
| SCMCN-1212H09-100 | CCMT09T3 | 12 | 12 | 100 | 6 | CS35090 | FT-15 |
| SCMCN-1616H09-100 | CCMT09T3 | 16 | 16 | 100 | 8 | CS35090 | FT-15 |
| SCMCN-2020K09-100 | CCMT09T3 | 20 | 20 | 125 | 10 | CS35090 | FT-15 |
| SCMCN-2525M09-100 | CCMT09T3 | 25 | 25 | 150 | 12.5 | CS35090 | FT-15 |
| SCMCN-2020K12-100 | CCMT1204 | 20 | 20 | 125 | 10 | CS40115 | FT-15 |
| SCMCN-2525M12-100 | CCMT1204 | 25 | 25 | 150 | 12.5 | CS40115 | FT-15 |
