▼建議刀片品牌：KYOCERA
| Order No. | Insert | Dimensions(mm) | Parts | Wrench | |||||
|---|---|---|---|---|---|---|---|---|---|
| Right/Left |  |
柄徑 | 工作寬度 | 長度 | 最小加工徑 | 頭長 | 最大切深 |  |
 |
| DCON | WF | LF | DAXIN | LH | CDX | ||||
| L08H-SIGER08A | GER100~200-A | 8 | 4.8 | 100 | 8 | 20 | 1.5 | CS20038 | FT-6 |
| L10K-SIGER10B | GER100~300-B | 10 | 6.2 | 125 | 10 | 25 | 2.2 | CS22050 | FT-7 |
| L10K-SIGER12B | GER100~300-B | 10 | 7.0 | 125 | 12 | 30 | 2.2 | CS22050 | FT-7 |
| L12M-SIGER14B | GER100~300-B | 12 | 8.0 | 150 | 14 | 30 | 2.2 | CS22050 | FT-7 |
| L16M-SIGER14B-L20 | GER100~300-B | 16 | 8.0 | 150 | 14 | 20 | 2.2 | CS22050 | FT-7 |
| L20M-SIGER16C-L20 | GER100~300-C | 20 | 9.0 | 150 | 16 | 20 | 2.5 | CS25061S | FT-7 |
| L25M-SIGER25C-L20 | GER100~300-C | 25 | 13.5 | 150 | 25 | 20 | 2.5 | CS25061S | FT-7 |
| L25M-SIGER25C | GER100~300-C | 25 | 13.5 | 150 | 25 | 45 | 2.5 | CS25061S | FT-7 |
