SVVBN 72.5°

Please click the picture to enlarge.

Спецификация

Order No.InsertDimensions(mm)PartsWrench
Right/Left H B LF WF
SVVBN-2020K11 VBMT1103 20 20 125 10 - - CS25060 FT-7 -
SVVBN-2525M11 VBMT1103 25 25 150 12.5 - - CS25060 FT-7 -
SVVBN-2020K16 VBMT1604 20 20 125 10 SMV-321 SN535 CS35115/
CS35119S
FT-15 LW035
SVVBN-2020K16 VBMT1604 25 25 150 12.5 SMV-321 SN535 CS35115/
CS35119S
FT-15 LW035
