| Order No. | Insert | Dimensions(mm) | Parts | Wrench | ||||
|---|---|---|---|---|---|---|---|---|
| Right/Left |  |
H | B | LF | LH | WF |  |
 |
| SCKCR/L-2020K09 | CCMT09T3 | 20 | 20 | 125 | 22 | 25 | CS35090 | FT-15 |
| SCKCR/L-2525M09 | CCMT09T3 | 25 | 25 | 150 | 25 | 32 | CS35090 | FT-15 |
| SCKCR/L-2020K12 | CCMT1204 | 20 | 20 | 125 | 22 | 25 | CS40115 | FT-15 |
| SCKCR/L-2525M12 | CCMT1204 | 25 | 25 | 150 | 25 | 32 | CS40115 | FT-15 |
